MRCOOL 1.5 Ton VersaPro® Central Ducted Heat Pump Condenser | R-454B – MVP-18-HP-C-230A00-O
MRCOOL 1.5 Ton VersaPro® Central Ducted Heat Pump Condenser | R-454B – MVP-18-HP-C-230A00-O
Summary
The 1.5 Ton MRCOOL® VersaPro® Central Ducted Heat Pump Condenser (model MVP-18-HP-C-230A00-O) delivers efficient, quiet, year-round comfort with a compact, side-discharge design. Its variable-speed DC inverter provides smooth temperature control, while eco-forward R-454B refrigerant supports lower environmental impact. It pairs seamlessly with the VersaPro® Central Ducted Air Handler to create a dependable whole-home system, and includes a MRCOOL® Smart Thermostat for effortless control.
Important
R-454B refrigerant. Variable-speed inverter. Side-discharge, compact footprint. Includes MRCOOL® Smart Thermostat (Wi-Fi enabled).
What's Included
- Outdoor Condenser (MVP-18-HP-C-230A00-O)
- MRCOOL® Smart Thermostat (Wi-Fi required for setup)
- Owner’s & Installation Manuals
- Sound-deadening pads; braze-to-flare adapters
- 5/8"→3/4" flare adapter (for 18K Regular Heat series)
Features
- High-efficiency variable-speed DC inverter
- Eco-forward R-454B refrigerant
- Self-diagnostics with error code readout
- Side-discharge cabinet for flexible placement
- Wi-Fi/app compatible via included MRCOOL® Smart Thermostat
- Pairs with VersaPro® Central Ducted Air Handlers
Technical Specifications
| Brand / Series | MRCOOL / VersaPro® Central Ducted Condenser |
| Model | MVP-18-HP-C-230A00-O |
| Unit Type | Split System Heat Pump (Condenser) |
| Tonnage | 1.5 Ton (18,000 BTU) |
| Cooling Capacity (BTU) | 18,000 |
| Heating Capacity (BTU) | 18,000 |
| SEER2 | 18.8 |
| EER2 | 11 |
| HSPF4 / HSPF5 | 9.1 / 7.0 |
| Airflow (CFM) | 1450.9 |
| Refrigerant | R-454B (A2L) |
| Refrigerant Volume | 51.15 oz (factory charge) |
| Liquid / Suction Line Sizes | 3/8" / 3/4" |
| Rated Line Length / Max | 25 ft (7.5 m) / 98.4 ft (30 m) |
| Max Elevation (ODU above IDU) | 65.6 ft (20 m) |
| Additional Refrigerant | 0.7 oz/ft beyond standard length (for 3/8" liquid) |
| Voltage / Phase / Hz | 208–230V / 1-Phase / 60 Hz |
| Max Fuse (A) / MCA (A) | 20 / 16 |
| Decibel Rating | 55 dBA (typical) |
| Net Dimensions (W × H × D) | 31.69" × 21.81" × 12.99" |
| Net / Gross Weight | 77 lbs / 84 lbs |
| Cabinet Color | Gray |
| Wi-Fi / App Compatible | Yes (Smart Thermostat included) |
| ETL / AHRI Certified | Yes / Yes |
| Contains Electronics / Chemicals / Compressed Gas | Yes / Yes / Yes |
| Equipment Type | Condenser (outdoor unit) |
Compatibility & Pairing
| Works With | VersaPro® Central Ducted Air Handler |
| Indoor Model | MVP-18-HP-MUAH-230A00-O |
| System Type | 24V Central Ducted Split, R-454B |
Warranty Information
- Base Parts Warranty: 10 Years (limited)
- Base Compressor Warranty: 10 Years (limited)
Manuals & Downloads
Safety & Install Notes
- Install on a solid, level base or rated wall bracket; follow clearances and anchoring guidance.
- Use 3/8" liquid and 3/4" suction lines; observe rated/max line length and elevation. Add refrigerant at 0.7 oz/ft beyond the standard line length.
- Perform proper vacuum and leak testing; charge as liquid and follow R-454B handling safety.
- Follow national/local codes. Installation and servicing should be performed by qualified personnel.
Environmental & Efficiency Features
Utilizes low-GWP R-454B refrigerant and a high-efficiency inverter for strong performance and reduced energy use. Compact side-discharge cabinet fits tight spaces and helps simplify placement.
