Bravo Pisa 9,000 BTU Single Zone Ceiling Cassette, 230V, R32 - Ductless Mini Split Heat Pump
Bravo7-Yr WarrantySKU: BRV-P09LS-230VO09CT
Product specifications
- Voltage
- 230V
- SEER
- 22.0
- WiFi
- Included
- Zone
- Single Zone
- Type
- Ceiling Cassette
- Freon
R32
Choose Your Configuration
Save 10% on these accessories
ARMBRIDGE Mini Split Wall Mounting Bracket High Load Capacity Zinc, Vibration-Absorbing (Up to 550 lbs Each)-10%$49.00
ARMBRIDGE Heavy-Duty Mini Split Ground Stand, Zinc-Coated Brackets for 24,000–60,000 BTU Units Weatherproof Design, 330+ lbs Capacity-10%$89.00
ARMBRIDGE 30 AMP Fusible Metallic Disconnect Box Durable Enclosed Disconnect for Residential and Light Commercial HVAC Systems-10%$29.00
ARMBRIDGE Non-Metallic A/C Whip 3/4" x 6 ft – Pre-Wired Liquid tight Conduit with 8/2 & 10/1 Wires for HVAC & Air Conditioner Power Connection-10%$34.00
FREE Delivery
Ships from the nearest of our three US warehouses, leaves in 1–2 business days. Shipping policy
BRAVO · PISA
Built for year-round comfort
BRV-P09LS-230VO09CT
System Specs
| Cooling Capacity | 9,000 BTU/h |
|---|---|
| SEER2 | 22.0 |
| Voltage | 230V |
| Refrigerant | R32 |
|---|---|
| Compressor | Inverter |
| Warranty | 7-Yr Compressor / 5-Yr Parts |
Pisa Series Description
Bravo Pisa 9,000 BTU Single Zone Ceiling Cassette Experience reliable cooling and heating with the Bravo Pisa Series 9,000 BTU Single Zone Ceiling Cassette Mini Split System. This 230V R32 inverter system delivers SEER2 22.0 efficiency, perfect for spaces 100-300 sq ft.
6 Modes for Maximum Comfort
Engineered to adapt to every season, every room, every need.
Maintain a comfortable indoor temperature by automatically switching between heating and cooling as needed. Ideal for year-round use.
WHEREVER YOU ARE
Control your comfort, your way
- Easy scheduling & timer
- Multiple ways to control your comfort
- Smart geo location
- In-app support & assistance
- Voice control
IN THE BOX
Everything included with this system
- Bravo Pisa 9,000 BTU Outdoor Condenser, 230V, R32 - Ductless Mini Split Air Conditioner Heat Pump
- Bravo Pisa 9,000 BTU Indoor Ceiling Cassette, 230V, R32 - Ductless Mini Split Air Conditioner Heat Pump
- Indoor Ceiling Cassette — BRV-PNL09-18CT
WARRANTY
BACKED BY AC BRAVO
Industry-leading protection on every unit
Compressor: 7-year coverage
With product registration after professional installation.
Parts & components: 5-year coverage
All major components and refrigerant circuit parts.
Technical Specifications
Series Comparison Table
Technical specifications for every model in the series — this product is one of them.
Indoor Model
| Specification | BRV-P09CT-230VI | BRV-P12CT-230VI | BRV-P18CT-230VI | BRV-P24CT-230VI |
|---|---|---|---|---|
| Panel Model | BRV-PNL09-18CT | BRV-PNL09-18CT | BRV-PNL09-18CT | BRV-P24CT-230VI |
| Outdoor Model | BRV-P09LS-230VO | BRV-P12LS-230VO | BRV-P18LS-230VO | BRV-P24LS-230VO |
| Power Supply (V-Ph-Hz) | 208~230-1-60 | 208~230-1-60 | 208~230-1-60 | 208~230-1-60 |
| Cooling – Rated Capacity (Btu/h) | 9,000 | 12,000 | 18,000 | 24,000 |
| Cooling – EER2 | 11.0 | 9.5 | 9.5 | 9.5 |
| Cooling – SEER2 | 20.0 | 20.0 | 20.0 | 20.0 |
| Heating – Rated Capacity (Btu/h) | 9,000 | 12,000 | 18,500 | 24,000 |
| Heating – HSPF2-4 | 9.5 | 9.5 | 9.5 | 9.5 |
| Heating – COP2 (W/W) | 3.8 | 3.5 | 2.9 | 3.5 |
| Minimum Circuit Ampacity (A) | 10 | 11 | 12 | 17 |
| Max Fuse (A) | 15 | 15 | 20 | 25 |
| Indoor Air Flow – Turbo/Hi/Mi/Lo/Mute (CFM) | 329/300/270/217/194 | 360/320/260/200/190 | 441/394/335/282/253 | 836/765/630/530/482 |
| Indoor Noise Level – Turbo/Hi/Mi/Lo/Mute (dB(A)) | 43/41/37/33/32 | 45/43/39/35/32 | 48/46/42/39/37 | 51/48/44/40/37 |
| Indoor Unit – Dimensions WxDxH (in) | 22.44×22.44×10.24 | 22.44×22.44×10.24 | 22.44×22.44×10.24 | 32.99×32.99×10 |
| Indoor Unit – Packing WxDxH (in) | 28.27×25.87×11.85 | 28.27×25.87×11.85 | 28.27×25.87×11.85 | 36.81×36.81×11.42 |
| Indoor Unit – Net/Gross Weight (lbs.) | 31.9 / 38.6 | 31.9 / 38.6 | 31.9 / 38.6 | 51.8 / 59.5 |
| Outdoor Side Noise Level (dB(A)) | 53 | 55 | 55 | 60 |
| Outdoor Unit – Dimensions WxDxH (in) | 30.98×11.42×19.61 | 31.5×12.01×21.69 | 33.54×13.74×23.7 | 36.1×14.76×27.56 |
| Outdoor Unit – Packing WxDxH (in) | 32.2×12.8×20.28 | 32.87×13.39×23.03 | 35.04×15.16×24.72 | 37.4×16.54×28.82 |
| Outdoor Unit – Net/Gross Weight (lbs.) | 50.7 / 57.3 | 51.8 / 58.4 | 66.8 / 74.5 | 88.2 / 97.0 |
| Refrigerant Type / Pre-charge (oz) | R32 / 21.16 | R32 / 20.46 | R32 / 37.74 | R32 / 42.33 |
| Refrigerant Precharge Length (ft) | 25 | 25 | 25 | 25 |
| Refrigerant Piping – Liquid/Gas Side (in) | 1/4" / 3/8" | 1/4" / 3/8" | 1/4" / 3/8" | 1/4" / 1/2" |
| Max Refrigerant Pipe Length (ft) | 49 | 49 | 65 | 65 |
| Max Height Diff Indoor/Outdoor (ft) | 33 | 33 | 49 | 49 |
| Ambient Temperature Range – Cooling Indoor (°F) | 62~89 | 62~89 | 62~89 | 62~89 |
| Ambient Temperature Range – Cooling Outdoor (°F) | 5~127 | 5~127 | 5~127 | 5~127 |
| Ambient Temperature Range – Heating Indoor (°F) | 32~86 | 32~86 | 32~86 | 32~86 |
| Ambient Temperature Range – Heating Outdoor (°F) | -4~75 | -4~75 | -4~75 | -4~75 |
Frequently asked questions.
What’s included in this system?
A complete single-zone system: the ceiling cassette indoor unit and its matching Bravo Pisa outdoor condenser. Choose a line-set kit length at checkout, or supply your own.
What size room does it suit?
It is rated at 9,000 BTU — size it to your room’s square footage and insulation for the best match.
Does it heat as well as cool?
Yes — it is an inverter heat pump that both cools and heats.
What refrigerant does it use?
R32. The system ships factory pre-charged; a licensed installer adjusts the charge for your line length.
Who should install it?
A licensed HVAC professional — required for the refrigerant, electrical, and startup work, and to keep the manufacturer warranty valid.
What warranty does it come with?
BRAVO backs it with a 7-year compressor and 5-year parts limited warranty (with professional installation and registration).
Manufacturer Technical Support
Reach your brand's tech support team directly
You may also like
- R454BSEER2 21.1HEATS down to −22°FCOOLS up to 122°F
7-Yr Warranty
Cooper & HunterCooper & Hunter Hyper Heat 12,000 BTU Single Zone Ceiling Cassette, 230V, R454B - Ductless Mini Split Air Conditioner Heat PumpFree Shipping
- R32SEER2 22.0Heats & Cools
7-Yr Warranty
BravoBravo Pisa 24,000 BTU Single Zone Ceiling Cassette, 230V, R32 - Ductless Mini Split Heat PumpFree Shipping
- R32SEER2 22.0Heats & Cools
7-Yr Warranty
BravoBravo Pisa 18,000 BTU Single Zone Ceiling Cassette, 230V, R32 - Ductless Mini Split Heat PumpFree Shipping
- R32SEER2 22.0Heats & Cools
7-Yr Warranty
BravoBravo Pisa 12,000 BTU Single Zone Ceiling Cassette, 230V, R32 - Ductless Mini Split Heat PumpFree Shipping
Bravo Pisa 9,000 BTU Single Zone Ceiling Cassette
Experience reliable cooling and heating with the Bravo Pisa Series 9,000 BTU Single Zone Ceiling Cassette Mini Split System. This 230V R32 inverter system delivers SEER2 22.0 efficiency, perfect for spaces 100-300 sq ft.
INCLUDED IN YOUR ORDER:
- Bravo Pisa 9,000 BTU Ceiling Cassette Indoor Unit (BRV-P09CT-230VI)
- Bravo Pisa 9,000 BTU Outdoor Condenser (BRV-P09LS-230VO)
- WiFi control included
- Wireless remote control
- Inverter compressor
Key Specifications
- Capacity: 9,000 BTU/h (0.75 Ton)
- SEER2: 22.0
- Voltage: 208-230V/60Hz
- Refrigerant: R32
- Coverage: 100-300 sq ft
- Compressor: Inverter
- WiFi: Included
Installation kit options available — choose 16ft, 25ft, or 50ft line set.
