Bravo Roma 12,000 BTU Outdoor Single Zone Condenser, 115V, R32 - Ductless Mini Split Air Conditioner Heat Pump
Bravo7-Yr WarrantySKU: BRV-R12LS-115VO
Choose Your Configuration
Save 10% on these accessories
ARMBRIDGE Mini Split Wall Mounting Bracket High Load Capacity Zinc, Vibration-Absorbing (Up to 550 lbs Each)-10%$49.00
ARMBRIDGE Heavy-Duty Mini Split Ground Stand, Zinc-Coated Brackets for 24,000–60,000 BTU Units Weatherproof Design, 330+ lbs Capacity-10%$89.00
ARMBRIDGE 30 AMP Fusible Metallic Disconnect Box Durable Enclosed Disconnect for Residential and Light Commercial HVAC Systems-10%$29.00
ARMBRIDGE Non-Metallic A/C Whip 3/4" x 6 ft – Pre-Wired Liquid tight Conduit with 8/2 & 10/1 Wires for HVAC & Air Conditioner Power Connection-10%$34.00
FREE Delivery
Ships from the nearest of our three US warehouses, leaves in 1–2 business days. Shipping policy
BRAVO · OUTDOOR UNIT
Built for year-round comfort
BRV-R12LS-115VO
Product Description
The Bravo Roma 12,000 BTU outdoor condenser (model BRV-R12LS-115VO) is the outdoor half of an R32 single-zone ductless mini split heat-pump system, designed for 115V power. Pair it with a matching Bravo Roma single-zone indoor unit to build your system.
6 Modes for Maximum Comfort
Engineered to adapt to every season, every room, every need.
Maintain a comfortable indoor temperature by automatically switching between heating and cooling as needed. Ideal for year-round use.
WHEREVER YOU ARE
Control your comfort, your way
- Easy scheduling & timer
- Multiple ways to control your comfort
- Smart geo location
- In-app support & assistance
- Voice control
WARRANTY
BACKED BY AC BRAVO
Industry-leading protection on every unit
Compressor: 7-year coverage
With product registration after professional installation.
Parts & components: 5-year coverage
All major components and refrigerant circuit parts.
Technical Specifications
Series Comparison Table
Technical specifications for every model in the series — this product is one of them.
Parameter
| Specification | Indoor Model |
|---|---|
| BRV-M07WM-230VI | BRV-M09WM-230VI |
| Power SupplyV-Ph-Hz | 208~230-1-60 |
| Cooling Rated CapacityBtu/h | 7,000 |
| Heating Rated CapacityBtu/h | 7,000 |
| Max FuseA | 5 |
| Indoor Air FlowCFM | 353 |
| Indoor Noise LeveldB(A) | 40 |
| Indoor Unit Dimensions (WxDxH)in | 31.02x7.80x11.50 |
| Indoor Unit Packing (WxDxH)in | 34.65x14.57x11.42 |
| Indoor Unit Net/Gross Weightlbs. | 17.60/22.00 |
| Refrigerant Piping Liquid / Gas Sidein | 1/4’’ / 3/8’’ |
| Operation Temperature Range°F | 60.8~89.6 |
Parameter
| Specification | Outdoor Model |
|---|---|
| BRV-M18-230VO | BRV-M24-230VO |
| Power SupplyV-Ph-Hz | 208~230-1-60 |
| Cooling CapacityBtu/h | 17,700 (3,800-19,800) |
| EER2Btu/h | 3.60 |
| SEER2Btu/h | 22 |
| Heating Rated CapacityBtu/h | 18,000 (4,200-22,000) |
| HSPF2-4Btu/h | 10 |
| COP2W/W | 3.8 |
| Minimum Circuit AmpacityA | 20 |
| Max FuseA | 20 |
| Outdoor Air FlowCFM | 1529 |
| Outdoor Side Noise LeveldB(A) | 54 |
| Outdoor Unit Dimensions (WxDxH)in | 34.65x13.90x21.93 |
| Outdoor Unit Packing (WxDxH)in | 35.55x15.04x24.21 |
| Outdoor Unit Net Weightlbs. | 75.0/80.5 |
| Refrigerant Type / Volumeoz | R32/38.8 |
| Refrigerant Prechargeft | 24.6 |
| Refrigerant Piping Liquid Side / Gas Sidein | 1/4" / 3/8" |
| Max Refrigerant Pipe Lengthft | 82 |
| Ambient Temperature Outdoor (Cooling)°F | -13~125.6 |
| Ambient Temperature Outdoor (Heating)°F | -13~75.2 |
Manufacturer Technical Support
Reach your brand's tech support team directly
You may also like
- R32HEATS down to −13°FCOOLS up to 126°F
7-Yr Warranty
BravoBravo Milano 18,000 BTU Outdoor Condenser, 230V, R32 - Ductless Mini Split Air Conditioner Heat PumpFree Shipping
- R410ASEER2 23.4Heats & Cools
5-Yr Warranty
OLMOOLMO Sierra 24,000 BTU Outdoor Condenser, 230V, R410A - Ductless Mini Split Air Conditioner Heat PumpFree Shipping
- R410ASEER2 22.9Heats & Cools
7-Yr Warranty
Cooper & HunterCooper & Hunter MES 18,000 BTU Outdoor Condenser, 230V, R410A - Ductless Mini Split Air Conditioner Heat PumpFree Shipping
- R32HEATS down to −13°FCOOLS up to 126°F
7-Yr Warranty
BravoBravo Milano 24,000 BTU Outdoor Condenser, 230V, R32 - Ductless Mini Split Air Conditioner Heat PumpFree Shipping
The Bravo Roma 12,000 BTU outdoor condenser (model BRV-R12LS-115VO) is the outdoor half of an R32 single-zone ductless mini split heat-pump system, designed for 115V power. Pair it with a matching Bravo Roma single-zone indoor unit to build your system.
Key Features
- Outdoor condenser (heat pump) — single-zone system, connects to one matching Bravo Roma indoor unit
- 12,000 BTU nominal capacity
- Inverter heat pump — efficient cooling and heating
- R32 refrigerant, factory pre-charged
Specifications — BRV-R12LS-115VO Outdoor Unit
| Power Supply | 115V, 1 Ph, 60 Hz |
| Cooling / Heating Capacity | 12,000 Btu/h nominal |
| Compressor | Inverter |
| Refrigerant | R32, factory pre-charged |
| Max. Connectable Indoor Units | 1 (single-zone) |
Works With
Connects to a matching Bravo Roma 12,000 BTU single-zone indoor unit (sold separately) on the same R32 platform.
Frequently Asked Questions
Is the indoor unit included?
No — this listing is the outdoor condenser only. Pair it with a matching Bravo Roma single-zone indoor unit, sold separately.
Who should install it?
A licensed HVAC professional — required for the refrigerant, electrical, and startup work, and to keep the manufacturer warranty valid.
